Earthing terminal for PV mounting systems
Št. art. 5051520 | EAN 4012197368715
- Opis izdelka
-
Opis izdelkaPre-mounted earthing terminal for the inclusion of PV mounting systems in the equipotential bonding. Suitable for the inclusion of the PV mounting systems in an external lightning protection system.
• Lightning current-compatible up to 100 kA (10/350)
• Rapid mounting through integrated spring mechanism
• For round conductor fastening RD 8–10
• To fasten single/multi-wire cables: 6–50 mm²
• For profiles with 10 mm groove
• Meets the requirements of DIN EN 62561-1
-
- Tehnični podatki
-
Tehnični podatki
Dimenzija 8-10mm Maks. premer okroglega vodnika, vodnik 1 10 mm Material Nerjaveče jeklo 1.4301 Min. premer okroglega vodnika, vodnik 1 8 mm Prileg RD8-10 + 6-50mm² mm Primerno za Okrogli vodnik Primerno za povezavo drugo Sposobnost prenašanja toka strele H/100 kA Vrsta povezovalnika Večnamenska povezovalna sponka Vrsta pritrdilnega vijaka Pritrdilni vijak Dimenzije
Dolžina 40 mm Širina 43 mm Višina 34 mm CO2 odtis (Product Carbon Footprint)
CO₂ Footprint (GWP) 0,5919 kg CO₂e Declared Unit (LCA) Units Declared Unit Quantity (LCA) 1 Determination date of CO2 value 2025-05-14T00:00:00.000+0200 Odtis CO2 (GWP) od zibelke do vrat 0,5919 kg CO2e / 1 Kos - Vsi tipi
- Prenosi
-
Podatkovni list 249 PV10 6-50V2A / 5051520 , 0.15MB , pdfREACH Izjava o skladnosti 249 PV10 6-50V2A / 5051520 , 0.12MB , pdfRoHS Izjava o skladnosti 249 PV10 6-50V2A / 5051520 , 0.13MB , pdfNavodila za montažo PV mounting systems Magic PV Flat Glue , 3.57MB , pdfNavodila za montažo PV mounting systems Magic PV Flat Basic , 3.93MB , pdfNavodila za montažo PV mounting systems for pitched roofs , 3.91MB , pdfNavodila za montažo PV mounting systems Magic PV Pitch on trapezoidal roofs , 2.45MB , pdfNavodila za montažo PV mounting systems Magic PV Flat Pro , 5.26MB , pdf
